PW50

We offer a wide range of Yamaha PW50 replacement parts from OEM, aftermarket and our custom Aftermarket Minis brand parts. We make many of our own brand PW50 parts such as billet aluminum foot pegs, one piece throttle cables to get rid of the oil injection system, oil injection plug for the removal of oil injection system, complete handlebar kits, billet handlebar riser, billet rear brake perch, skid plate, billet ignition stator cover, billet rear end drive cover, billet quick turn throttle tub, sealed steering bearing kit, and many more parts for the Yamaha PW50. We also carry parts to keep your bike running at peak performance with genuine Mikuni Carburetor main jets, pilot jets and VM12 Carburetor rebuild kits. As for our OEM parts we carry genuine Yamaha brand pistons, rings, pin, needle bearings, seals, gaskets, electrical, plastics, kick start parts, drive shaft and other replacement part to keep your rider going.

Yamaha PW50 Bike Specifications

ENGINE

Engine Type 49cc air-cooled 2-stroke; reed-valve induction
Bore x Stroke 40.0mm x 39.2mm
Compression Ratio 6.0:1
Fuel Delivery VM12 Carburetor
Ignition CDI
Transmission Wet centrifugal automatic
Final Drive Shaft
Fuel Capacity 0.5 gal

CHASSIS

Suspension/Front 26mm telescopic fork; 2.4-in travel 2017+ Years
Suspension/Rear Unit swingarm; 2.0-in travel
Brakes/Front Drum
Brakes/Rear Drum
Tires/Front 2.50-10-4PR
Tires/Rear 2.50-10-4PR

DIMENSIONS

LxWxH 49.0 in x 24.0 in x 27.8 in
Seat Height 18.7 in
Wheelbase 33.7 in
Rake (Caster Angle) 25.5°
Trail 2.0 in
Max. Ground Clearance 3.7 in
Fuel Capacity 0.5 gal
Wet Weight*** 90 lb

OTHER*Manufacturer's Suggested Retail Price (MSRP) shown. Does not include tax, title, prep or destination charges. Actual prices set by dealer.
**Fuel Economy is estimated.
***Wet weight includes the vehicle with all standard equipment and all fluids, including oil, coolant (as applicable) and a full tank of fuel. It does not include the weight of options or accessories. Wet weight is useful in making real-world comparisons with other models.
